OVERVIEW


Over All is a collection of exterior luminaires for architectural and landscape lighting.

The innovative design simplifies the installation without requiring a back box. Over All can be fastened to any hard surface or mounted directly to the ground with a spike.

Suitable for installation in concrete slabs, pavers, wood decks in new construction or retrofit applications.

This series of uplighter is available in 3 sizes with a complete range of light distributions for accent lighting and wall washing.

FEATURES


3 sizes

Round design

Operating temperature -40°C / +40°C

IP67, IK08, UL Listed for wet location

Available in Aluminum Gray and Anthracite Gray

5 year limited warranty

*Remote LED driver required

SPECIFICATIONS


Power   2.5 to 20.5 watts

Output  164Im to 770lm

Distribution   Spot / Flood / Wide Flood / Asymmetric / Narrow elliptical

Color  2700 / 3000K / 4000 K

Cri   80 / 90

Controls Consult factory

Lumen maintenance  L80  70,000 Hours

BROCHURE

OPTICS

5 optics available for each size.

FEATURES

Ground mounting system with stake accessories available,
no backbox required.
